Webhook Integration

Overview

Outbound webhooks let WA Orbit push events out to your own systems in real time — a CRM, a data warehouse, Zapier, Make, n8n, or any HTTPS endpoint. Whenever an event you've subscribed to happens in your workspace, WA Orbit sends a JSON request to your URL, optionally signed so you can verify it really came from WA Orbit.

Manage them under More → Webhooks. Webhooks are shared across the whole workspace: every member sees every endpoint, no matter who created it. When an event happens, WA Orbit delivers it to every active endpoint in that workspace that subscribed to the event (or to the wildcard *).

Creating an Endpoint

Click Add a webhook on the index and fill in the form. The right rail shows a live sample payload and a Test fire action so you can wire up and validate your receiver before any real event arrives.

Event Types

These are the events you can subscribe an endpoint to. Subscribe to any subset — an endpoint only receives the events in its list.

Delivery Payload

Every delivery is a JSON body with the same outer "envelope" for all events; the event-specific fields live under data. The request is sent with Content-Type: application/json.

Envelope

Example — message_delivered

POST /your/endpoint HTTP/1.1
Host: api.yourbrand.example
Content-Type: application/json
X-WAOrbit-Signature: 9f86d081884c7d659a2feaa0c55ad015a3bf4f1b2b0b822cd15d6c15b0f00a08

{
  "id": "3a8f7e2c-91b5-4d0f-a7a1-d6c8e4b9f2c0",
  "event": "message_delivered",
  "eventType": "message_delivered",
  "created": "2026-05-29T18:32:08+00:00",
  "timestamp": 1780000328,
  "data": {
    "workspace_id": 42,
    "user_id": 7,
    "message_id": 918273,
    "wamid": "wamid.HBgLOTE5ODc2NTQzMjEwFQIAERgSM0E...",
    "recipient": "+919876543210",
    "status": "delivered",
    "timestamp": 1780000328,
    "error_code": null,
    "error_reason": null,
    "pricing": { "billable": true, "category": "marketing" },
    "conversation": { "id": "abc123...", "origin": { "type": "marketing" } }
  }
}

Signing & Verification

If you set a signing secret on an endpoint, every delivery includes this header:

X-WAOrbit-Signature: <hex>

The value is HMAC-SHA256 computed over the exact JSON request body, using your endpoint's secret as the key, encoded as lowercase hex.

Verifying in Node.js

const crypto = require('crypto');
const expected = crypto
  .createHmac('sha256', SECRET)
  .update(req.rawBody)
  .digest('hex');
const given = req.get('X-WAOrbit-Signature') || '';
const ok = expected.length === given.length &&
  crypto.timingSafeEqual(Buffer.from(expected), Buffer.from(given));
if (!ok) return res.status(401).end();

Verifying in PHP

$expected = hash_hmac('sha256', $rawBody, $secret);
$given    = $_SERVER['HTTP_X_WAORBIT_SIGNATURE'] ?? '';
if (!hash_equals($expected, $given)) {
  http_response_code(401);
  exit;
}

Delivery, Retries & Health

Each delivery is a single HTTP request with a 10-second timeout. A delivery counts as successful on any 2xx response; anything else counts as a failure.

An endpoint is automatically marked as failing after three failures in a row. It keeps receiving events while failing — the flag is just a health warning, not a pause.

Monitoring & Analytics

The Webhooks index gives you a live health overview across all endpoints in the workspace:

• Endpoints — total configured, plus active / paused counts.
• Events fired (24h) — deliveries in the last day.
• Success rate — percentage of 2xx responses over the last 24h.
• Latency p95 — 95th-percentile delivery latency.
• Event mix — the top events by volume over 24h.
• Recent deliveries — a feed of the latest attempts with their status codes.

Managing & Test-firing Endpoints

For each endpoint you can:

• Test fire — send a sample payload and see the live status code and latency.
• Toggle — pause or resume the endpoint.
• Edit — change the URL, events, secret, method, name, or environment.
• Delete — remove the endpoint and stop all deliveries to it.

Inbound vs Outbound

These are two completely different things — keep them straight:
